Wizone is your central management platform for Wi-Fi hotspot networks. It supports TP-Link Omada and Mikrotik hardware through a unified dashboard.

1. Create an account and log in
2. Add your first network site
3. Configure your vendor credentials
4. Start managing tickets and users

Sites represent your physical network locations. Each site is linked to a specific hardware vendor (Omada or Mikrotik).

• Add a site — From the dashboard, click "Add Site" and provide your controller/router credentials
• Monitor — View live connections and session data in real-time
• Edit / Delete — Manage site settings from the site detail page

Access tickets are vouchers for end-user Wi-Fi access. Each ticket has a username and password that users enter on the captive portal.

• Single ticket — Create one ticket at a time with custom settings
• Batch create — Generate up to 100 tickets at once
• Profiles — Choose duration: 1h, 3h, 1d, 7d, 30d, or unlimited
• Speed limits — Set upload/download speed per ticket
• Data limits — Optional data cap in MB

The captive portal is the page your Wi-Fi users see when they connect. They enter their ticket credentials to gain internet access.

• Configure your router/controller to redirect to the portal URL
• Users enter the ticket username and password
• Authentication is verified against FreeRADIUS
• After successful login, users are redirected to the configured URL
